B/W Laptop Ultrasound DW-580 + 2 probes

Name: B/W Laptop Ultrasound DW-580 + 2 probes
SKU: 17708
Price: 42999.00 ZAR
Availability: InStock

Portable Medical Handheld Infrared Vein Viewer FinderContec Infusion Pump SP750

R42,999.00

IN STOCK At Supplier , Delivery Is Estimated 10 – 20 Working Days

Add to wishlist

Compare

Categories: Laptop Ultrasound, Ultrasound Scanners Tags: ultrasound Machine, Ultrasound Scanner

Description

B/W laptop ultrasound DW-580

Product Description

Specification

item	value
Place of Origin	China
	Jiangsu
Brand Name	Dawei
Model Number	DW-580
Power Source	Electric
Warranty	2 Year
After-sale Service	Online technical support
Shelf Life	2 years
Quality Certification	CE
Instrument classification	Class II
Safety standard	GB15979-2002
Product name	B/W Medical Ultrasound Equipment
Display mode	2D
Scanning mode	B, 2B, 4B, B, BM
Probe	Convex Linear Transvaginal Probe
Language	English/Russian/Spanish/French/Arabic/Vietnamese/Portuguese/Indonesian
Battery	Built-in Lithium Battery
Screen	12.1 inch LCD
Gray scale	256 level
Movie playback	512 frames
Dynamic range	0-135dB

Packing & Delivery

More Info

1,	Description of equipment: mainly used in the abdomen, Urology, obstetrics and Gynecology, pediatrics, etc.
2,	Functional characteristics
2.1	All digital ultrasonic diagnostic instruments with high definition and rich function
2.2	The image is clear, easy to operate, and strong in endurance. It has great superiority in consultation in cities, townships and outdoor environments.
2.3	A variety of charging methods ensure more consultation in different environments.
2.4	3-4 hours extra long standby time
2.5	12.1 inch LED liquid crystal display
2.6	Powerful image post-processing functions
2.7	The first class digital imaging technology, the image is clearer
2.8	DBF all digital beamforming
2.9	DRF real-time dynamic reception of focus by point-by-point
2.10	DRA real-time dynamic sound velocity change
2.11	THI tissue harmonic imaging
2.12	RDA real-time dynamic aperture imaging
2.13	DFS numerical control dynamic frequency scanning
2.14	RDF real-time dynamic filtering
2.15	A stable and concise operating platform
2.16	Backlight silicone keyboard, more comfortable and wearable, darkroom use no longer worry
2.17	Intelligent menu, human-computer dialogue is easy and quick
2.18	Shows two puncture guidelines, adjustable angles, and positions.
2.19	The multiple rate shows that the diagnosis is more accurate.
2.20	External USB storage and image uploading are more convenient
2.21	Large volume movie playback, image automatic circulation demonstration
2.22	Abundant measurement functions: distance, circumference, area, volume, obstetric table, heart software package, etc.
3,	Performance introduction
3.1	Display: 12.1 inch LED medical display
3.2	Scanning mode: convex matrix / linear array / micro convex
3.3	Probe interface: Standard 1, 2 (optional), automatic identification function, support multiple probe work.
3.4	Interface: CN/EN/PT/FR/ES/RU interface
3.5	Display mode: B, B+B, 4B, B+M, M
3.6	Electron focusing: four-segment electron focusing
3.7	Postural markers: 97 species
3.8	3.5MHz Convex: 2.0MHz,2.5MHz,3.5MHz,4.0MHz,5.0MHz 5.0MHz Micro-convex: 4.0MHz,4.5MHz,5.0MHz,6.5MHz,7.0MHz 6.5MHz Transvaginal: 5.0MHz,5.5MHz,6.5MHz,7.5MHz,8.5MHz 7.5MHz Linear: 5.5MHz,6.5MHz,7.0MHz,7.5MHz,9.0MHz
3.9	Image mirroring: upper and lower mirrors, left and right mirrors, black and white flip, in any mode can be mirrored conversion, operation
3.10	The image can be rotated at 0 degrees, 90 degrees, 180 degrees, 270 degrees, and 360 degrees.
3.11	Measurements: distance, circumference, area, volume, heart rate, gestational age (BPD, GS, CRL, FL, HC, AC, EDD, AFI) expected date of birth, fetal weight display, and so on.
3.12	The function software package and measurement method can be selected through the trackball cursor.
3.13	Angle measurement, you can intuitively see the angle and length of the angle.
3.14	Have histogram function
3.15	Have depth measurement function
3.16	It has 16 obstetric measurement packages and has a fetal growth curve function.
3.17	In any imaging mode, the data can be measured in real-time
3.18	Automatic memory and generative function of obstetric data
3.19	Character display: date, clock, name, gender, age, doctor, hospital, annotation (full-screen character editing)
3.20	One key out of patient information entry function
3.21	Movie playback: 512 frames, continuous playback, or one by one view.
3.22	Permanent storage: built in 8G memory, more than 4000, supporting U disk storage (available for storage).
3.23	Single memory image time is less than 6 seconds
3.24	A key to find saved images can be found by the date named folder quickly found and a key export.
3.25	Grayscale: 256 level
3.26	With the function of puncture and guidance, the angle and position of the two puncture lines can be adjusted visually.
3.27	Lithotripsy positioning, dynamic target tracking function
3.28	Dynamic range: 0-135dB, step 8, with independent buttons, visually adjustable, adjustable cycle.
3.29	Intelligent TGC control: 8 segments.
3.30	Total gain: 0-100, step 2
3.31	Variable aperture, dynamic trace, dynamic digital filtering, etc.
3.32	2 stage visible tunable harmonics of tissue
3.33	8 kinds of fake color processing, etc.
3.34	The 4 frames are independent keys, visually adjustable, cycle adjustable, and can also be changed through the trackball cursor.
3.35	6 kinds of line correlation, with independent buttons, visually adjustable, circular adjustment, or trackball cursor changes.
3.36	The 8 types of gamma correction are independent keys, visually adjustable, cycle adjustable, and can also be changed through the trackball cursor.
3.37	Edge enhancement 4 level adjustable, with independent buttons, visually adjustable, adjustable cycle, also can be changed through the trackball cursor.
3.38	The scanning range can be adjusted to 4 levels, with independent buttons, visually adjustable, circular adjustment, and also can be changed by the trackball cursor.
3.39	Luminance key addition and subtraction enhancement and weakening function
3.40	Caps and Shift locking functions
3.41	Blind area: less than 4
3.42	Maximum display depth:3.5MHz:307mm 6.5MHz:189mm 7.5MHz:166mm 5.0MHz:205mm
3.43	Geometric accuracy: transverse less than 5%, longitudinal less than 5%
3.44	Resolution: the side is less than 2mm, and the axis is less than 1mm
3.45	Interface: RS-232 interface, VGA interface, VIDEO interface, USB interface 2, DICOM
3.46	Display rate: 6 display modes; lesion diagnosis is more accurate. When it is above 1.5 and over 1.8, the depth can be enhanced.
3.47	The Starting time is less than 10 seconds
3.48	Built-in 8800 Ma lithium battery
3.49	Power indicator light and charging indicator
3.50	Net weight 4.7KG
3.51	The button has a buzzing sound, but open/ close
3.52	Formulae of fast data measurement
3.53	You can quickly set time, name and other editors through the trackball and keyboard.
4,	Standard: 12.1 inch LCD; 3.5MHz electronic convex array probe.
5,	Accessories: 7.5MHz high frequency probe; 6.5MHz cavity probe; probe interface development dock; ultrasonic imaging workstation; portable trolley.
6,	Other
6.1	Medical device quality management system (ISO13485) certification
6.2	Equipment inspection report
6.3	EC Authentication
6.4	Two years of quality assurance
